Specifications

Operating Systems

Copier Specifications

Copying process	Electrostatic laser copy; Tandem; indirect
Toner system	Simitri HD® polymerised toner
Copy/print speed A4 mono (cpm)	22
Copy/print speed A4 colour (cpm)	22
Copy/print speed A3 mono (cpm)	14
Copy/print speed A3 colour (cpm)	14
Autoduplex speed A4 mono (cpm)	22
Autoduplex speed A4 colour (cpm)	22
1st Copy/print time mono (sec)	6.9
1st Copy/print time colour (sec)	8.3
Warm-up time (sec)	Approx. 20 * * Warm up time may vary depending on the operating environment and usage
Copy resolution (dpi)	600 x 600
Gradations	256 gradations
Original format	A5-A3
Magnification	25-400% in 0.1% steps; Autozooming
Copy functions	Chapter, Cover and page insertion; Proof copy (print and screen); Adjustment test print; Digital art functions; Job setting memory; Poster Mode; Image repeat; Overlay; Stamping; Copy Protection;

Printer Specifications

Print resolution (dpi)	1,800 x 600 1,200 x 1,200
Controller CPU Type	PowerPC MPC8536 @ 800 MHz
Page description language	PCL 6c (PCL 5c + XL3.0) PostScript 3 (CPSI 3016) XPS
Operating systems	Windows 2000/XP/XP64 Windows VISTA 32/64 Windows 7 32/64 Server 2000/2003/2003x64/2008/2008x64/2008 (R2) Macintosh 9.x/10.x Unix/Linux/Citrix
Printer fonts	80x PCL Latin; 137x PostScript 3 Emulation Latin
Print functions	Direct print of PCL, PS, TIFF, XPS, PDF, Encrypted PDF files and OOXML (docx, xlsx, pptx); Mixmedia and mixplex; Job programming "Easy Set”; Overlay; Watermark; Copy Protection, Carbon Copy Print

Scanner Specifications

Scan speed colour (opm)	Up to 160/160 ipm
Scan Speed mono (opm)	Up to 160/160 ipm
Scan resolution (dpi)	Max.: 600 x 600
Scan modes	Network TWAIN scan Scan-to-email (scan-to-Me) Scan-to-FTP Scan-to-SMB (scan-to-Home) Scan-to-Box Scan-to-WebDAV Scan-to-DPWS Scan-to-USB
File formats	JPEG; TIFF; PDF; PDF/A 1a and 1b (optional); Compact PDF; Encrypted PDF; Searchable PDF (optional); XPS; Compact XPS; PPTX and searchable PPTX (optional)
Scan destinations	2,100 (single + group); LDAP support
Scan functions	Annotation (text/time/date) for PDF; up to 400 job programs; Realtime scan previev

Fax Specifications

Fax standard	Super G3 (optional)
Fax transmission	Analogue; i-Fax; Colour i-Fax (RFC3949-C); IP-Fax
Fax resolution (dpi)	Max.: 600 x 600 (ultra-fine)
Fax compression	MH; MR; MMR; JBIG
Fax modem (Kbps)	Up to 33.6
Fax destinations	2,100 (single + group)
Fax functions	Polling; Time shift; PC-Fax; Receipt to confidential box; Receipt to email/FTP/SMB; up to 400 job programs

User box specification

Max. storable documents	Up to 3,000 documents or 10,000 pages
Type of user boxes	Public;  personal (with password or authentication);  group (with authentication)
Type of system boxes	Secure print; encrypted PDF print; fax receiving; fax polling
User box functionality	Reprint; combination; download; sending (email/FTP/SMB and Fax); copy box to box

System Specifications

System memory standard (MB)	2,048
System hard disc standard (GB)	250
Network protocols	TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP
Frame types	Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic document feeder	Up to 100 originals; A6-A3; 35-163 gsm R-ADF, Dualscan ADF
Paper size	A6-SRA3, customised paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight (g/m²)	52-300 gsm
Paper input capacity (sheets)	Standard: 1,150 Max: 3,650
Paper trays standard	Tray 1: 500 sheets, A5-A3, 52-256 gsm Tray 2: 500 sheets, A5-SR Write a review Your Name Your Review Note: HTML is not translated! Rating     Bad           Good Enter the code in the box below Continue
